heartbeat Linux: Complete Guide to System Uptime Monitoring and High Availability

The heartbeat service in Linux is a critical component for maintaining high availability and monitoring system uptime. Originally developed as part of the Linux-HA (High Availability) project, heartbeat provides cluster membership and messaging services that ensure your systems remain operational even during hardware failures or network issues.

What is Linux Heartbeat?

Linux heartbeat is a daemon that monitors the health of cluster nodes by sending periodic “heartbeat” messages between systems. When a node fails to respond within a specified timeframe, heartbeat can automatically trigger failover procedures to maintain service availability.

Key features of Linux heartbeat include:

• Node monitoring: Continuous health checks of cluster members
• Automatic failover: Seamless service migration during failures
• Resource management: Control of shared resources like IP addresses and services
• Split-brain prevention: Mechanisms to avoid dual-master scenarios

Understanding Heartbeat Architecture

Heartbeat operates on a simple yet effective principle. Each node in a cluster periodically sends heartbeat messages to other nodes via configured communication channels. These channels can include:

• Ethernet: Network-based heartbeat messages
• Serial cable: Direct hardware connection
• Multicast: Broadcasting to multiple nodes simultaneously

Installing Heartbeat on Linux

Installation varies depending on your Linux distribution. Here are the most common methods:

Ubuntu/Debian Installation

# Update package repository
sudo apt update

# Install heartbeat and related packages
sudo apt install heartbeat heartbeat-dev

# Verify installation
heartbeat -V

CentOS/RHEL Installation

# Install EPEL repository first
sudo yum install epel-release

# Install heartbeat
sudo yum install heartbeat

# For newer versions, use dnf
sudo dnf install heartbeat

Manual Installation from Source

# Download heartbeat source
wget http://linux-ha.org/download/heartbeat-3.0.6.tar.bz2

# Extract and compile
tar -xjf heartbeat-3.0.6.tar.bz2
cd heartbeat-3.0.6
./configure --prefix=/usr --sysconfdir=/etc
make && sudo make install

Essential Heartbeat Configuration Files

Heartbeat uses three primary configuration files located in /etc/ha.d/:

1. ha.cf (Main Configuration)

The main configuration file defines cluster parameters:

# Sample /etc/ha.d/ha.cf
debugfile /var/log/ha-debug
logfile /var/log/ha-log
logfacility local0
keepalive 2
deadtime 30
warntime 10
initdead 120
udpport 694
auto_failback on
node server1
node server2
ucast eth0 192.168.1.10
ucast eth0 192.168.1.11

2. authkeys (Authentication)

Defines authentication methods for cluster communication:

# Sample /etc/ha.d/authkeys
auth 1
1 crc
# 2 sha1 your-secret-key
# 3 md5 your-secret-key

Important: Set proper permissions for security:

sudo chmod 600 /etc/ha.d/authkeys

3. haresources (Resource Configuration)

Defines which resources are managed by which nodes:

# Sample /etc/ha.d/haresources
server1 IPaddr::192.168.1.100/24/eth0 httpd
server2 IPaddr::192.168.1.101/24/eth0 mysql

Practical Heartbeat Configuration Examples

Basic Two-Node Cluster Setup

Let’s configure a simple two-node cluster for web server high availability:

Node 1 (web01) Configuration:

# /etc/ha.d/ha.cf on web01
debugfile /var/log/ha-debug
logfile /var/log/ha-log
keepalive 2
deadtime 10
warntime 5
initdead 60
udpport 694
auto_failback off
node web01
node web02
ucast eth0 192.168.1.20

Resource Configuration:

# /etc/ha.d/haresources on both nodes
web01 IPaddr::192.168.1.100/24/eth0 apache2

Advanced Multi-Node Configuration

For more complex setups with multiple services:

# Advanced ha.cf configuration
debugfile /var/log/ha-debug
logfile /var/log/ha-log
logfacility local0
keepalive 1
deadtime 10
warntime 5
initdead 60
udpport 694
auto_failback on
compression bz2
traditional_compression on

# Node definitions
node db-master
node db-slave
node web-server

# Communication methods
mcast eth0 225.0.0.1 694 1 0
ucast eth1 10.0.1.10
ucast eth1 10.0.1.11
ucast eth1 10.0.1.12

# Ping nodes for network connectivity checks
ping 8.8.8.8
ping 8.8.4.4

Heartbeat Service Management

Starting and Stopping Services

# Start heartbeat service
sudo systemctl start heartbeat

# Stop heartbeat service
sudo systemctl stop heartbeat

# Restart heartbeat service
sudo systemctl restart heartbeat

# Enable automatic startup
sudo systemctl enable heartbeat

# Check service status
sudo systemctl status heartbeat

Legacy Init System Commands

# For older systems using init
sudo service heartbeat start
sudo service heartbeat stop
sudo service heartbeat restart
sudo chkconfig heartbeat on

Monitoring Heartbeat Status

Real-time Cluster Status

Use the cl_status command to check cluster status:

# Check cluster status
cl_status listnodes

# Sample output:
# web01 active
# web02 active

# Check resource status
cl_status rscstatus

# Sample output:
# Resource Name    Node Name    Status
# IPaddr           web01        running
# apache2          web01        running

Log Analysis

Monitor heartbeat logs for troubleshooting:

# View recent heartbeat logs
sudo tail -f /var/log/ha-log

# Check for errors
sudo grep -i error /var/log/ha-log

# Monitor debug information
sudo tail -f /var/log/ha-debug

Sample Log Output:

Aug 26 09:52:15 web01 heartbeat: info: Heartbeat restart on node web01
Aug 26 09:52:15 web01 heartbeat: info: Link web01:eth0 up.
Aug 26 09:52:16 web01 heartbeat: info: Status update for node web02: up
Aug 26 09:52:17 web01 heartbeat: info: All resources started.

Testing Failover Scenarios

Manual Failover Testing

Test your configuration by simulating failures:

# Stop heartbeat on primary node to test failover
sudo systemctl stop heartbeat

# Check if resources moved to secondary node
cl_status rscstatus

# Monitor logs on secondary node
sudo tail -f /var/log/ha-log

Network Disconnection Simulation

# Simulate network failure using iptables
sudo iptables -A INPUT -p udp --dport 694 -j DROP
sudo iptables -A OUTPUT -p udp --dport 694 -j DROP

# Remove rules to restore connectivity
sudo iptables -D INPUT -p udp --dport 694 -j DROP
sudo iptables -D OUTPUT -p udp --dport 694 -j DROP

Troubleshooting Common Issues

Split-Brain Scenarios

Split-brain occurs when cluster nodes can’t communicate but both remain active:

# Check for split-brain in logs
sudo grep -i "split.*brain" /var/log/ha-log

# Configure STONITH (Shoot The Other Node In The Head)
# Add to ha.cf:
stonith_host web01 ipmi web01-ipmi
stonith_host web02 ipmi web02-ipmi

Authentication Failures

Common authentication issues and solutions:

# Check authkeys permissions
ls -la /etc/ha.d/authkeys

# Should show: -rw------- 1 root root

# Verify authkeys syntax
sudo heartbeat -t

Resource Management Issues

# Manually start/stop resources
sudo /etc/ha.d/resource.d/IPaddr 192.168.1.100/24/eth0 start
sudo /etc/ha.d/resource.d/IPaddr 192.168.1.100/24/eth0 stop

# Check resource script functionality
sudo /etc/ha.d/resource.d/apache2 status

Advanced Heartbeat Features

Custom Resource Agents

Create custom resource agents for specific applications:

#!/bin/bash
# Custom resource agent example
# /etc/ha.d/resource.d/myapp

case "$1" in
start)
    /usr/local/bin/myapp --daemon
    ;;
stop)
    killall myapp
    ;;
status)
    if pgrep myapp > /dev/null; then
        echo "running"
        exit 0
    else
        echo "stopped"
        exit 1
    fi
    ;;
*)
    echo "Usage: $0 {start|stop|status}"
    exit 1
    ;;
esac

Heartbeat with Pacemaker Integration

Modern setups often use Pacemaker with Heartbeat:

# Install Pacemaker cluster stack
sudo apt install pacemaker corosync

# Configure cluster with both heartbeat and pacemaker
sudo crm configure property stonith-enabled=false
sudo crm configure primitive webserver ocf:heartbeat:apache

Performance Optimization

Tuning Heartbeat Parameters

Optimize heartbeat for your environment:

# Low-latency configuration
keepalive 1
deadtime 5
warntime 2

# High-latency/WAN configuration
keepalive 5
deadtime 30
warntime 15

Network Configuration Best Practices

• Dedicated heartbeat network: Use separate network interfaces
• Multiple communication paths: Configure redundant channels
• Proper MTU settings: Ensure consistent MTU across cluster nodes

Security Considerations

Authentication Methods

Choose appropriate authentication for your security requirements:

# Strong authentication with SHA1
auth 2
2 sha1 your-very-secure-passphrase-here

# MD5 authentication
auth 3
3 md5 another-secure-passphrase

Firewall Configuration

# Allow heartbeat traffic through firewall
sudo iptables -A INPUT -p udp --dport 694 -j ACCEPT
sudo iptables -A INPUT -p tcp --dport 5560 -j ACCEPT

# For firewalld (CentOS/RHEL)
sudo firewall-cmd --permanent --add-service=high-availability
sudo firewall-cmd --reload

Monitoring and Alerting

Integration with Monitoring Systems

Create scripts for external monitoring integration:

#!/bin/bash
# Heartbeat status check for Nagios/Zabbix
CLUSTER_STATUS=$(cl_status listnodes | grep -c "active")
EXPECTED_NODES=2

if [ "$CLUSTER_STATUS" -eq "$EXPECTED_NODES" ]; then
    echo "OK - All cluster nodes active"
    exit 0
else
    echo "CRITICAL - Cluster node(s) down"
    exit 2
fi

Automated Health Checks

# Cron job for periodic health checks
# Add to /etc/crontab
*/5 * * * * root /usr/local/bin/check_heartbeat.sh

Migration and Upgrades

Upgrading Heartbeat

Safe upgrade procedures:

# Stop heartbeat on secondary nodes first
sudo systemctl stop heartbeat

# Upgrade packages
sudo apt upgrade heartbeat

# Start services and verify
sudo systemctl start heartbeat
cl_status listnodes

Migrating to Modern Alternatives

Consider migrating to modern cluster solutions:

• Corosync/Pacemaker: More feature-rich cluster stack
• Keepalived: Lightweight alternative for simple failover
• Consul: Service mesh with health checking

Best Practices and Recommendations

Configuration Best Practices

• Use dedicated heartbeat interfaces to avoid network congestion
• Configure multiple communication paths for redundancy
• Set appropriate timeouts based on your network latency
• Test failover scenarios regularly to ensure functionality
• Monitor cluster logs continuously for early issue detection

Common Pitfalls to Avoid

• Incorrect authkeys permissions leading to authentication failures
• Insufficient network bandwidth for heartbeat messages
• Missing STONITH configuration in production environments
• Overly aggressive timeout settings causing false positives

Linux heartbeat remains a robust solution for uptime monitoring and high availability clustering. While newer alternatives exist, understanding heartbeat principles provides valuable insights into cluster management and system reliability. Proper configuration, monitoring, and testing ensure your critical services maintain maximum uptime even during hardware failures or network disruptions.

By implementing the configurations and best practices outlined in this guide, you’ll be equipped to deploy and maintain highly available Linux systems that can withstand various failure scenarios while maintaining service continuity for your users and applications.
