depmod Command Linux: Complete Guide to Generate Module Dependencies

The depmod command is a critical system administration tool in Linux that generates module dependency maps for the kernel. This powerful utility analyzes kernel modules and creates dependency files that enable the kernel to automatically load required modules when needed.

What is the depmod Command?

depmod (dependency modules) is a Linux command that creates a dependency file for kernel modules. It scans the module directory, analyzes the symbols each module exports and imports, and generates files that describe the dependencies between modules. This information is crucial for the kernel’s module loading system.

Why is depmod Important?

When you install new kernel modules or update existing ones, the kernel needs to understand the relationships between modules. Some modules depend on others to function properly. The depmod command ensures that:

• Module dependencies are properly mapped
• Required modules are loaded automatically
• The system can resolve circular dependencies
• Module loading order is optimized

Basic Syntax

depmod [options] [kernel_version]

Common Options and Parameters

Essential Options

How depmod Works

When executed, depmod performs the following operations:

1. Scans module directories – Looks for .ko files in /lib/modules/$(uname -r)/
2. Analyzes symbols – Examines exported and imported symbols in each module
3. Creates dependency maps – Builds relationships between modules
4. Generates output files – Creates several dependency files in the modules directory

Generated Files

depmod creates several important files in the /lib/modules/$(uname -r)/ directory:

modules.dep

The main dependency file listing module dependencies in makefile format.

modules.dep.bin

Binary version of modules.dep for faster loading.

modules.symbols

Lists symbols exported by each module.

modules.symbols.bin

Binary version of modules.symbols.

modules.alias

Contains alias information for modules.

Practical Examples

Example 1: Basic depmod Execution

sudo depmod

Expected Output:

# No output typically shown - runs silently
# Dependencies are generated in background

Example 2: Verbose Mode

sudo depmod -v

Sample Output:

Finding dependencies for /lib/modules/5.4.0-74-generic/kernel/drivers/net/ethernet/intel/e1000/e1000.ko
Finding dependencies for /lib/modules/5.4.0-74-generic/kernel/drivers/usb/storage/usb-storage.ko
Finding dependencies for /lib/modules/5.4.0-74-generic/kernel/sound/core/snd.ko
...

Example 3: Check Specific Kernel Version

sudo depmod 5.4.0-74-generic

This generates dependencies for the specified kernel version instead of the current running kernel.

Example 4: Dry Run Mode

sudo depmod -n

Sample Output:

kernel/drivers/net/ethernet/intel/e1000/e1000.ko:
kernel/drivers/usb/storage/usb-storage.ko: kernel/drivers/scsi/scsi_mod.ko
kernel/sound/core/snd.ko:
kernel/sound/core/snd-timer.ko: kernel/sound/core/snd.ko

Example 5: Report Unresolved Symbols

sudo depmod -e

Potential Output:

WARNING: /lib/modules/5.4.0-74-generic/kernel/drivers/example/example.ko needs unknown symbol: undefined_function

Advanced Usage Scenarios

Custom Module Directory

sudo depmod -b /custom/modules/path

This specifies a custom base directory for modules instead of the default /lib/modules.

Using System.map File

sudo depmod -F /boot/System.map-5.4.0-74-generic

Explicitly specify which System.map file to use for symbol resolution.

Quick Update Check

sudo depmod -A

Only regenerate dependency files if they are older than the modules themselves.

Viewing Generated Dependencies

Examining modules.dep

head -10 /lib/modules/$(uname -r)/modules.dep

Sample Output:

kernel/arch/x86/crypto/aesni-intel.ko:
kernel/arch/x86/crypto/ghash-clmulni-intel.ko:
kernel/crypto/af_alg.ko:
kernel/crypto/algif_hash.ko: kernel/crypto/af_alg.ko kernel/crypto/hash.ko
kernel/crypto/algif_skcipher.ko: kernel/crypto/af_alg.ko kernel/crypto/skcipher.ko

Checking Module Information

modinfo e1000

Sample Output:

filename:       /lib/modules/5.4.0-74-generic/kernel/drivers/net/ethernet/intel/e1000/e1000.ko
version:        7.3.21-k8-NAPI
license:        GPL
description:    Intel(R) PRO/1000 Network Driver
author:         Intel Corporation, <[email protected]>
depends:
retpoline:      Y

Troubleshooting Common Issues

Module Not Found Errors

If you encounter module loading issues:

# Regenerate dependencies
sudo depmod -a

# Check for missing dependencies
sudo depmod -e

# Verify module exists
find /lib/modules/$(uname -r) -name "module_name.ko"

Circular Dependencies

When modules have circular dependencies:

sudo depmod -v 2>&1 | grep -i cycle

Permission Issues

Always run depmod with root privileges:

sudo depmod

Best Practices

Regular Maintenance

• Run depmod after installing new modules
• Update dependencies after kernel updates
• Use -A option for routine checks
• Always backup before making changes

Development Workflow

# After compiling new modules
make modules_install
sudo depmod

# Verify dependencies
sudo depmod -n | grep your_module

Integration with Other Commands

Working with modprobe

# After running depmod, test module loading
sudo modprobe your_module

# Check loaded modules
lsmod | grep your_module

Kernel Updates

# After kernel installation
sudo depmod $(uname -r)
sudo update-initramfs -u

Performance Considerations

For systems with many modules, consider:

• Using -A for incremental updates
• Running during maintenance windows
• Monitoring system load during execution

Security Implications

Be aware that depmod:

• Requires root privileges
• Modifies system-critical files
• Should be run only from trusted sources
• Can affect system boot process

Automation Scripts

Simple Maintenance Script

#!/bin/bash
# Update module dependencies
echo "Updating module dependencies..."
sudo depmod -A

if [ $? -eq 0 ]; then
    echo "Dependencies updated successfully"
else
    echo "Error updating dependencies"
    exit 1
fi

Conclusion

The depmod command is essential for maintaining a healthy Linux system with properly managed kernel modules. Understanding its functionality, options, and integration with other system tools enables effective system administration and troubleshooting. Regular use of depmod ensures your system’s module dependencies remain current and functional, preventing potential boot and runtime issues.

Whether you’re a system administrator managing production servers or a developer working with custom kernel modules, mastering depmod is crucial for maintaining system stability and performance. Remember to always run it with appropriate privileges and test your changes in a safe environment before applying them to critical systems.
